This shacman h3000 dump truck for sale in Mali is specially designed for heavy-duty non-paved scenarios such as engineering and mining areas. Its power transmission system has undergone special structural optimization to meet the requirements of frequent starts, low-speed high-torque, and continuous high-load operation in such scenarios. Equipped with a high-power diesel engine and a multi-speed transmission, as well as an engineering drive axle that has been calibrated for heavy loads, it can easily handle scenarios such as mountain climbing and getting out of potholes on construction sites even when fully loaded.
This shacman h3000 dump truck for sale in Mali is adapted to the reliability requirements of long-term continuous operation. Its 6×4 rear double-axle drive form further enhances the driving adhesion on unpaved roads, reduces the risk of skidding, and meets the transportation operation requirements on complex road surfaces.
The chassis load-bearing structure of this shacman dump truck for sale in Mali has been comprehensively strengthened to meet the demands of heavy-load transportation. The frame is made of high-strength manganese steel, and the double-layer I-shaped cross-section longitudinal beams have undergone local thickening treatment in core force-bearing areas such as the installation position of the traction seat, the fixed position of the lifting mechanism, and the rear section of the frame. The overall bending and torsional stiffness can meet the requirements of frequent driving under full load on complex road surfaces such as potholes at construction sites and rocky roads in mining areas.
The center of gravity of this shacman dump truck for sale in Mali has been structurally optimized. It has stronger stability when driving and turning under heavy load and reduces the risk of rollover. The connection part between its lifting bracket and the vehicle frame has been reinforced. The lifting action is smooth and stable. Even under full load, there will be no problem of tilting or jamming when lifting the cargo box, and the unloading efficiency is higher.
This shacman dump truck for sale in Mali cargo box is made of high-strength wear-resistant steel as a whole. The thickness of the bottom plate and side plates has been thickened, and X-shaped cross reinforcing ribs have been added inside. When transporting heavy bulk materials such as sand, gravel, ores, and construction waste, it is less likely to have deformation and perforation problems, significantly increasing the service life of the cargo box.
10 Tires H3000 Shacman Dump Truck for Sale in Mali
Vehicle Model: H3000
Drive Configuration: 6×4
Steering: Left-hand drive
Version: Reinforced
Model No.: SX3255MT384
Cab: Standard cab (flat roof)
Engine: WP10.380E22
Engine Brand: Weichai, 380 HP, Euro II
Transmission: 10JSD180 (iron housing) + QH50 PTO
Transmission Brand/Gears: Fast Gear, 10-speed
Front Axle: HD 9.5T
Rear Axle: 16T HD dual-stage cast axle (widened), 5.92 ratio
Fuel Tank: 300L aluminum alloy
Tires: 12.00R20 mixed tread pattern
